PG 8581 [WW AD LD 240V]
Dental washer-disinfector with hot and DI water connection, liquid dispensing & EcoDry function.
- Performance/cycle, e.g., 44 handpieces or 44 suction devicesFurther stacking options
Further instruments can be also be reprocessed in the upper or lower basket in each cycle. - Safety through monitoring - wash pressure and spray arm monitoringFor a reliable result
Outstanding reprocessing results are achieved because the jet pressure and spray arms are monitored continuously and a decline in jet pressure or load blockage is detected immediately - 42% less water consumption compared to predecessor model1Save water with flawless results
The variable-speed heating pump adjusts its speeds and thus the wash pressure in line with the relevant requirements in the program blocks – high pressure facilitates the removal of stubborn soiling, while low pressure guarantees the complete soaking of all the load items. As a result, the consumption of water and energy remains particularly low with optimum wash pressure at all times. Outstanding results while ensuring sustainable use of resources. - Convenient drying support - EcoDryUnique
At the end of the program the machine door opens automatically as soon as the temperature in the wash cabinet has fallen below 70 °C, thanks to the AutoOpen function. This allows residual moisture to escape easily from the wash cabinet and the washed items to dry more quickly. - Total security - link to process documentation possibleEnd-to-end documentation
The optional addition of a module for process documentation is provided via a communication slot. The Ethernet module is used for documentation via software. The RS 232 module must be used for documentation within a USB solution or via a printer.
Product benefits
EcoDry via patented AutoOpen function2
Convenient drying support
Quick drying: At the end of the reprocessing program the appliance door opens automatically.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
EcoDry via patented AutoOpen function2
Convenient drying support
Quick drying: At the end of the reprocessing program the appliance door opens automatically.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Clear text display
Text display
Everything at a glance: The display shows everything as clear text in the country-specific language.
AutoClose3
Automatically closing door
A light touch is all it takes: With AutoClose, the door closes by itself.
Large selection of components
Reprocess flexibly
Flexible and comprehensive components for optimum cleaning performance and a variety of reprocessing options.
Can be built under a countertop
For a consistent look
The machine can be easily integrated under a countertop.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Product details
PG 8581 [WW AD LD 240V]
EAN 4002515645079 / Article number 63858127CDN / Material number 10254390
EAN 4002515645079 / Article number 63858127CDN / Material number 10254390
| Construction type | Freestanding appliance, can be built-under, slim |
|---|---|
| Outer casing | Stainless steel |
| Can be built-under | |
| AutoClose – automatic door lock | AutoClose3 A light touch is all it takes: With AutoClose, the door closes by itself. |
| Buzzer, acoustic signal at end of program | |
| Easy-to-service construction |
| Surgical saliva extractors per cycle [number] | 44 |
|---|---|
| Handpieces per cycle [number] | 44 |
| Circulation pump, Qmax in gal/min (l/min.) | 132.1 (500) |
|---|---|
| Maximum final rinse temperature in °F (°C) | 199 (93) |
| Usable wash cabinet volume in ft³ (l) | 5.12 (145) ft³ (l) |
| Tested operating hours Note Our machines undergo intensive testing under laboratory conditions. The actual operating hours may vary depending on actual usage behaviour, maintenance, and care of the machine. | 15000 |
| Control type | TouchControl |
|---|---|
| Program selection | Touch on metal Touch on Metal Greater user convenience and easy surface cleaning. |
| Short cut buttons | |
| Max. delay start in h | 24 |
| Programmability | programmable |
| Programs [number] | 6 |
| Free program slots [number] | 2 |
| A0 value controls | |
| Automatic program restart | Program failure protection Time-saving and safe: The program failure protection facilitates the continuation of the cleaning and disinfection process after a short interruption, such as a power cut. If the success of the reprocessing process should be at risk, the appliance issues a corresponding warning message. |
| Time left display | |
| Program sequence indicator | |
| Choice of display language |
| Electrical connection | 2 AC 240V 60HZ |
|---|---|
| Electric heater rating in kW | 5.4 |
| Total rated load in kW | 6.2 |
| Fuse rating in A | 30 |
| Length of power cord in ft (m) Note The length refers to the supply lead on the outside of the appliance. | 5 (1.8) |
| Electrical connection | 3 AC 240V 60HZ |
|---|---|
| Electric heater rating in kW | 5.4 |
| Total rated load in kW | 6.2 |
| Fuse rating in A | 20 |
| Cold water [number] | 1 |
|---|---|
| Cold water for steam condenser [number] | 1 |
| Hot water [number] Efficient hot water connection Connection to the warm water supply saves time and energy. | 1 |
| Fully demineralized water [number] Di water supply Thanks to the connection for fully demineralized water (demin. water), these washer-disinfectors achieve optimum reprocessing results. Rinsing with demin. water also protects valuable wash items from deposits and corrosion. | 1 |
| Required flow pressure in kPa Notes for variants with feed pump for DI water This value applies to cold, hot, and demin. water; however, it does not apply to the demin. water intake for the highly purified water variants as a feed pump is used in this case. | 200-1000 |
| Maximum drain pump height (delivery head) in in (cm) | 39 3/8 (100) |
| Integrated water softener | |
| Maximum water hardness (cold water / hot water) in (mmol/l) | 62.595 (10.7) |
| Drain pump [DN] | 0.866 (22) |
| Water protection system Waterproof System (WPS) Protection against flooding: In the event of problems, the system stops water intake automatically. | Waterproof system |
| External dimensions, net height in in. (mm) | 32 7/8 (835) |
|---|---|
| External dimensions, net width in in. (mm) | 23 5/8 (600) |
| External dimensions, net depth in in. (mm) | 23 5/8 (600) |
| Packaging dimensions, gross height in in. (mm) Note Including packaging | 37 1/16 (940) |
| Packaging dimensions, gross width in in. (mm) Note Including packaging | 26 5/8 (675) |
| Packaging dimensions, gross depth in in. (mm) Note Including packaging | 29 3/8 (745) |
| Wash cabinet, usable height in in. (mm) | 20 1/2 (520) |
| Wash cabinet, usable width in in. (mm) | 20 7/8 (530) |
| Wash cabinet, depth of upper basket in in. (mm) | 18 11/16 (474) |
| Wash cabinet, depth of lower basket in in. (mm) | 20 1/2 (520) |
| Net weight in lb (kg) | 163.142 (74) |
| Gross weight in lb (kg) Note Including packaging | 178.575 (81) |
| Emission sound pressure level in the workplace Emission sound pressure level at the workplace The emission sound pressure level provides a value for the noise created by the machine. Miele Professional appliances have an extremely low sound pressure level. | <lt/>70 dB(A) re 20 µPa |
|---|---|
| Heat dissipation into the room in MJ/h Heat output into the room During operation warm air is vented into the surrounding room. The released amount of heat/time depends on the set temperatures and the intensity of use. The stated maximum value can be used to control the temperature of the area or to calculate an increase in room temperature. | 1.5 |
| Vario TD Intensive | |
|---|---|
| Vario TD Dental | |
| Vario TD Dental + | |
| Special 93°C–10' |
| 1 door dispenser for rinsing agent | |
|---|---|
| 1 dispenser pump for liquid cleaning agent | |
| 1 dispenser pump for neutralizing agent | |
| Volume flow control | |
| Steam condenser | |
| Spray pressure monitoring | |
| Spray arm monitoring | |
| Interface for process documentation (optional) | |
| Multi-component filter system | |
| Variable-speed heating pump | The heart of perfect results The speed of the pump and thus the wash pressure is adjusted in line with the relevant requirements In the individual program blocks – high pressure facilitates the removal of stubborn soiling, while low pressure guarantees the complete wetting of all the wash items. As a result, the consumption of water and energy remains particularly low with optimum wash pressure at all times. |
| Load carrier - direct coupling | |
| EcoDry | EcoDry via patented AutoOpen function2 Quick drying: At the end of the reprocessing program the appliance door opens automatically. |
| In-door salt container | |
| Miele Service optical interface | |
| Wash cabinet seamlessly welded using laser technology | |
| Heater elements outside wash cabinet | |
| Wash cabinet made of high-quality stainless steel (1.4301 / 304) | |
| Extensive components (option) |
| IP safety class according to EN 60529: IP 21 | |
|---|---|
| EN 61010-1 | |
| EN 61010-2-040 | |
| c CSA us | |
| Health Canada, Medical Device class II |
Additional components and consumables
Find additional components and consumables to go with this product
Additional components for dental technology
Find here the components that can be bought additionally for this product.
Additional consumables for dental technology
Find here the consumables that can be bought additionally for this product.
Notes
-
1.compared to VarioTD program for G 7881
-
2.German Patent DE 102 007 008 950 B4
-
3.European patent EP 1 733 675 B1
